Main features
- Light weight, compact size and small installation space.
- Higher operating speed saves time and is ideal for complex and small weldments
Specifications
- Shape
- A2PF301-JNN
- A2PF501-JNN
- A2PF1001-JNN
- Max. payload
- 300kg
- 500kg
- 1000kg
- Spin speed max
- 3.1rad/s(180°/s)
- 2.8rad/s (162°/s)
- 2.9rad/s (166°/s)
- 最大傾斜速度
- 2.2rad/s(125°/s)
- 1.5rad/s(84°/s)
- 1.4rad/s(82°/s)
- Max. allowable load moment of table shaft
- 294N.m
- 392N.m
- 882N.m
- Maximum allowable load moment on inclined shaft
- 882N.m
- 1347N.m
- 3704N.m
- Repeatability
- ±0.08mm
(Position of R250)
- ±0.08mm
(Position of R250)
- ±0.08mm
(Position of R250)
- Stop position
- Arbitrary
- Arbitrary
- Arbitrary
- Mass
- 260kg
- 260kg
- 470kg
