Arc welding A new type of welding that reduces and eliminates weld spatter, eliminating the post-process clean-up operations.Low heat input reduces workpiece distortion. Arc welding A new type of welding that reduces and eliminates weld spatter, eliminating the post-process clean-up operations.Low heat input reduces workpiece distortion.
  • Synchro-feed welding system

    Defining a new level of finish quality through the elimination of weld spatter.

  • Cold tandem welding system

    High-quality welding with low heat input to reduce workpiece distortion while improving productivity with an increased weld deposit.

Select product

  • Low payload(3~6kg)

    1. FD-B6
    2. FD-V8
    3. FD-B6L
    4. FD-V8L
    1. FD-H5
    2. FD-S3
    3. FD-G3
    FD-V6 Manipulator specs

    Manipulator specsLow payload(3~6kg)

    • 1
    • 2
    •   FD-B6 FD-V8 FD-B6L FD-V8L
      Type NB6 NV8 NB6L NV8L
      Number of Axes 6 6 6 6
      Maximum pay load capacity 6kg 8kg 6kg 8kg
      Positional Repeatability ±0.08mm ±0.08mm 士0.08mm 士0.08mm
      Drive capacity 3132W 3016W 4832W 5000W
      Working
      range
      Arm J1 ±170°(±50°) ±170° (±50°) 士170°(士50°) ±170° (±50°)
      J2 –155°〜+90° –155°〜+90° -155°〜+100° -155°〜+100°
      J3 –170°〜+245° –170°〜+190° -170°〜+190° -170°〜+260°
      Wrist J4 ±155° ±180° ±土155°(土170°) 士180°
      J5 –45°〜+225° –50°〜+230° -45°〜+225°(注5) -50°〜+230°
      J6 ±205° ±360° 士205°(士360°) 士360°
    •   FD-H5 FD-S3 FD-G3
      Type NH5 NS3 NG3
      Number of Axes 6 5
      Maximum pay load capacity 5kg 3kg 3kg
      Positional Repeatability ±0.05mm ±0.08mm ±0.08mm
      Drive capacity 1440W 390W 1400W
      Working
      range
      Arm J1 ±170° ±135° (±45°) ±170°
      J2 –125°〜+90° –160°〜+65° ±50°
      J3 –140°〜+245° –130°〜+125° ±150°
      Wrist J4 ±190° ±180° ±210°
      J5 –30°〜+210° –40°〜+220° ±130°
      J6 ±360° ±360°
  • Medium payload(15~50kg)

    1. FD-B15
    2. FD-V25
    FD-B15 Manipulator specs

    Manipulator specsMedium payload(15~50kg)

    •   FD-B15 FD-V25
      Type NB15 NV25
      Number of Axes 6 6
      Maximum pay load capacity 15kg 25kg
      Positional Repeatability ±0.08mm 士0.07mm
      Drive capacity 5600W 5600W
      Working
      range
      Arm J1 ±170° (±50°) 土170°(土50°)
      J2 –155°〜+100° -155°〜+100°
      J3 –170°〜+305° (注8) -170°〜+260°
      Wrist J4 ±155° 土180°
      J5 –37°〜+217° -50°〜+230°
      J6 ±205° 土360°
  • 7-axis robot

    1. FD-B4S
    2. FD-B4LS
    3. FD-V6S
    4. FD-V6LS
    5. FD-V20S
    Manipulator specs FD-B4S

    Manipulator specs7-axis robot

    •   FD-B4S FD-B4LS FD-V6S FD-V6LS FD-V20S
      Structure Vertical articulated type Vertical articulated type Vertical articulated type Vertical articulated type Vertical articulated type
      Number of Axes 7 7 7 7 7
      Maximum pay load capacity 4kg 4kg 6kg 6kg 20kg
      Positional Repeatability ±0.08mm ±0.08mm ±0.08mm ±0.08mm ±0.08mm
      Drive method AC servo motor AC servo motor AC servo motor AC servo motor AC servo motor
      Drive capacity 3550W 5650W 3600W 6000W 6600W
      Position feedback Absolute encoder Absolute encoder Absolute encoder Absolute encoder Absolute encoder
      Working
      range
      Arm J1 ±170° ±170° ±170° ±170° ±170°
      J2 –145°〜+70° –145°〜+75° –145°〜+70° –145°〜+75° –145°〜+75°
      J7 ±90° ±90° ±90° ±90° ±90°
      J3 –170°〜+142.6° –170°〜+154° –170°〜+149° –170°〜+160° –170°〜+160°
      Wrist J4 ±155° ±155° ±180° ±180° ±180°
      J5 –45°〜+225° –45°〜+225° –50°〜+225° –50°〜+225° –50°〜+230°
      J6 ±205° ±205° ±360° ±360° ±360°
