Laser search FD-QD High accuracy workpiece position detection with laser precision. Laser search FD-QD High accuracy workpiece position detection with laser precision.

Main features

  • Faster and more accurate than a touch sensor.

  • Can accommodate high accuracy for a wide range of applications from thin plate to medium thickness plate.

  • Can be used for applications other than welding.

  • Allows users to visually confirm the recognition result while using a teach pendent.

  • Enables automatic change of the welding condition based on the recognition result.

  • Allows recognition of various welding joints with easy operation.

Video

  • Video

    Workpiece position detection sensor using a laser

Specifications

Workpiece position sensing


(1.5 seconds is the 2-way displacement detection rate for 1 position.)
Welding line copy
×
Weld joint profile detection
Supported sensor combinations
Touch sensor Arc sensor or TIG arc sensor with search speeds of 100cm or less.
Suitable workpieces
Plate thickness 1.0mm and greater
Accuracy

±0.5mm(Search speeds of 100cm or less. While nonmetals are acceptable, the part cannot be glossy.)
Workpiece material


Can be used together with a combination of a touch sensor, arc sensor or TIG arc sensor with search speeds of 100cm or less. While nonmetals are acceptable, the part cannot be glossy.
  • Product catalog
  • Standard specification sheet

*User registration is necessary to download CAD data.
Be advised that the registration ID of anyone from another company in the same industry may be deleted without notice.
