Main features
-
Applicable to workpieces of medium material thickness or greater.
-
Maximum search speed of 360 cm/min.
-
Value-priced touch position sensor.
-
Excellent touch-sensing choice for workpieces whose surfaces contain rust or non-conductive scale.
-
Built-in controller eliminates additional mounting consideration.
-
High voltage type touch sensors are also available.
Specifications
- Workpiece position sensing
- ○(5 second detection rate per location (requires straight section without bending))
- Welding line copy
- -
- Weld joint profile detection
- -
- Supported sensor combinations
- This sensor can be used together with an arc sensor or TIG arc sensor.
- Suitable workpieces
- Plate thickness 3.2mm and greater
- Accuracy
- +/-1.0mm (However this is when the arc and pool are stable)
- Workpiece material
- Energizes entire workpiece, including surface.
Login
Login
*User registration is necessary to download CAD data.
Be advised that the registration ID of anyone from another company in the same industry may be deleted without notice.
Video
Workpiece position detection sensor by touching the welding wire.
