Main features
-
Weld tracking correction works on curved seams and in cases
where heat distortion is dynamically moving the weld seam. -
Applicable to workpieces with medium and greater thickness.
-
Least expensive seam tracking sensor option from Daihen.
-
Eliminates issues with workpiece interference and service access
that result from mounting of peripheral equipment around the welding torch. *Eliminates issues with workpiece interference and service access that result from mounting of peripheral equipment around the welding torch.
Specifications
- Workpiece position sensing
- ×
- Welding line copy
- ○
- Weld joint profile detection
- ×
- Supported sensor combinations
- Usable in combination with a touch or laser sensor
- Suitable workpieces
- Plate thickness 3.2mm and greater
- Accuracy
- ±1.0mm(However this is when the arc and pool are stable)
- Workpiece material
- Iron and stainless steel
