Main features
- Improved operation rate and welding quality of welding robots
- ・Automatically eliminates spatter in the torch nozzle (L-10748, K-2725)
・Simultaneous cleaning and application of spatter adhesion prevention agent (L-10748, K-2725)
・Wire-cutting function (K-2726) plus brushing (L-10748, K-2725)
Specifications
- Shape
- L-10748
- K-2725
- K-2726
- Inner diameter of nozzle
- Specify Ø13, Ø16 and Ø19.
- Power supply
- AC100V 50/60Hz
- Power consumption (W)
- 57
- 50
- Air source (MPa)
- 0.49
- Not required
- Not required
- Dimensions ( Length × Width × Height) (mm)
- 438×195×233
- 498×188×227
- 132×190×143
- Mass (kg)
- 11
- 9.7
- 4.5
- Applicable wire diameter (mm)
- Ø1.6 or less
- Accessories
- Guide fixing bracket
- Dedicated mounting bracket set
- Dedicated mounting bracket set
- Other
- Please purchase anti-spatter adherence liquid separately.Recommended product: 2670-026 (DAIHEN)
- -
- Function
- Dual nozzle cleaning
- ○（Dual）
- ○（Single）
- -
- Wire cut
- ○
- ○
- ○
- Brushing
- ○
- ○
- -
* L-10748, K-2725 does not support True-Constant-Contact torches (TCC torches).
