AImega Frendly series UTM-R3700F Compact and high performance welding automation. AImega Frendly series UTM-R3700F Compact and high performance welding automation.

Main features

  • Wide operating range

    Wide operating range (W2.7m x H1.6m) offers to meet various system layout.

  • Small footprint

    The compact rotation diameter (520mm) helps to minimize the equipment footprint.

  • High speed

    330 WPH (*) of transfer speed contributes to improve the equipment throughput.
    *: Vacuum chuck type

Specifications

Item
Specifications
Model name
UTM-R3700F
Structure
Vertical articulated type
Number of Axes
6
Payload
0.5kg/arm (including E/E)
Weight
74kg
Cleanliness (*)
Clamp type: ISO Class 3 (ISO-14644)
Vacuum chuck type: ISO Class 1 (ISO14644)

(*) Measured at the wafer transferring surface.

  • Product catalog
  • 2D CAD data
  • 3D CAD data

*User registration is necessary to download CAD data.
Be advised that the registration ID of anyone from another company in the same industry may be deleted without notice.
